Reading a Flat's Floor Plan Room by Room: A Checklist for Bangalore Buyers
Computer renders flatter every apartment, and drawings are harder to flatter. That is why careful reading repays the effort before a booking amount is paid in Bangalore. The sections below list the drawings to request, the sizes to test against the building rules and the habits that expose a weak layout.
Which Drawings to Ask For
The sales office holds three drawings. Each copy should carry dimensions, a north arrow and the unit number.
- Unit plan, showing room sizes, doors and windows
- Typical floor plan, with every flat, lift, staircase and corridor of one storey
- Master plan, giving the position of the tower and the outlook from each side
Marketing drawings exist to sell, so they use tiny furniture and leave out columns. The binding one is attached to the agreement for sale, and it has to agree with the sanctioned plan. If the two differ, get the reason in writing before booking.
How Busy Will the Building Feel?
Two numbers from the typical floor plan are enough. First count the flats on one floor, then divide the tower's total homes by its lifts. The lower the second figure, the shorter the lift queue in the morning rush and the quieter the lobby.
Density and ventilation could fill an article each. Here the focus is on how residents move through the home and which rooms are easy to get wrong.
Walking the Plan With a Pencil
Architects call the movement between rooms circulation. Mark the journeys of an ordinary day: shopping to the kitchen, a night trip to the bathroom, plates to the table and wet clothes to the balcony. Short, direct routes that avoid furniture are the sign of good planning.
The living room often fails this test. Suppose the way into the bedrooms slices through the seating area. Sofa and television wall are then permanently in the way. A layout that sends traffic along one edge keeps the rest of the room usable.
The cost of corridors
Passage space is bought at the same rate per square foot as a bedroom. Short ones mean an efficient plan, while long ones eat into the carpet area. A passage with a clear wall can at least double as storage.
Arriving at the Door
If the entrance opens directly into the living room, every visitor sees the whole home. A compact foyer, or a bend in the approach, adds privacy and makes room for shoes and parcels. The tower plan shows whether the door looks at a neighbour's door, at the lift or at a blank wall.
Distance from the lift works in both directions. Flats near it attract footfall and noise at the door, while those at the end of the corridor enjoy quiet along with a longer walk. Buyers should choose with both facts in mind.
Bye-Law Minimums for Kitchens and Bathrooms
The city's 2003 building bye-laws lay down the smallest sizes that are allowed. Real homes should beat them, but the figures give a baseline for judging a plan.
| Space | Least area | Least width |
|---|---|---|
| Kitchen, with separate dining | five square metres (roughly 54 sq ft) | 1.8 metres |
| Kitchen including dining | 7.5 square metres | 2.1 metres |
| Bathroom | 1.8 square metres | 1.2 metres |
| Bathroom with water closet | two square metres | 1.2 metres |
Width matters as much as area. A narrow kitchen cannot serve two people, and a narrow bathroom puts basin, closet and shower in one row with no room to move.
Reading the Kitchen and Bathroom Drawings
Parallel counters need a gap in which two people can pass, while a counter in an L shape needs a corner without breaks. Look for a wall that can take the refrigerator, a window on the outside and a utility corner for the washing machine and sink.
In the bathroom, make sure the door swings clear of basin and closet, the shower is at the far end and the window opens to the open air or a shaft. After possession, a common bathroom that opens onto the dining area draws many complaints.
Door Arcs and Widths
Each quarter-circle on a plan is a door's swing, and furniture cannot occupy that floor space. A door swinging against a wardrobe or a bed is a flaw that buyers live with permanently. Door widths count too, since big furniture and appliances must get past the main door and the bedroom doors.
Balcony Depth and Area
Depth is worth more than length, and a shallow balcony fits a clothes stand and little else, but a deeper one takes a pair of chairs and a small table. Find the room each balcony opens from, then check on the master plan what it faces.
The balcony is not part of carpet area. Request carpet area, balcony area and any terrace as three numbers, so two projects can be compared fairly.
Neighbours, Sight Lines and Sound
Some problems appear only on the typical floor plan. Bedroom windows that look into another flat across a narrow gap give little privacy. A wall adjoining the lift shaft, the stairs or the refuse room passes noise inside.
The master plan shows how far the next tower is. The bye-laws require lifts in any building 15 m high or taller, or one that goes beyond ground plus three storeys, so every tall tower has a lift core. Its position on the floor decides which flats stay quiet.
A Comparison Sheet
Keep a separate sheet for each shortlisted flat. Contrasts between two similar plans then stand out.
- Number of flats on a floor, and homes for each lift
- What a visitor sees on opening the main door
- Four everyday routes, and the points where furniture blocks them
- Combined area of the internal passages
- Width of the kitchen, its window and its utility space
- Width of each bathroom, its door swing and its window
- Each door arc, and the furniture it would hit
- The neighbour behind each wall, and the view from each window
Finally, take the marked plan to the show flat or the real unit and measure whatever looked doubtful. Layout differences seldom move the cost, but they shape everyday life in a home for years.
