Is the Bedroom Big Enough? Reading Room Sizes on a Bangalore Floor Plan

Before signing for a flat, it helps to ask a simple question: will my bed, my cupboard and I fit comfortably in each bedroom? The numbers needed to answer it are already on the floor plan. This guide supplies the legal floor set by Bangalore's rules, the sizes of common furniture, three worked room examples and a list of layout points to confirm in any Bangalore apartment.

What Bangalore's Rules Say

Under Bangalore's 2003 building bye-laws, a bedroom falls in the category of habitable rooms. A plan can be approved if it meets the following limits, yet a pleasant bedroom needs far more than the legal floor.

• Width: 2.4 m or more, which comes to a shade below 8 ft
• Height: 2.75 m or more between floor and slab, about 9 ft
• Headroom below any beam: 2.4 m
• Glazing and vents: one-sixth of the floor area or more, with doors not counted

Pay special attention to height if the interiors will include a false ceiling. In rooms with air conditioning, the clearance below the duct or false ceiling can drop to 2.4 m, which is also the beam headroom. Before booking, request the finished height of each bedroom and ask how deep any beam across it is.

Furniture Dimensions to Keep in Mind

Mattress sizes in India are fairly standard: 3 ft by 6 ft for a single, 5 ft by 6.5 ft for a queen and 6 ft by 6.5 ft for a king. Cupboards are about 2 ft in depth. Hinged doors swing outward and therefore claim one more strip of floor.

The frame makes a bed a few inches wider than its mattress, and a headboard lengthens it slightly. For two people to board the bed from either side, around 2 ft of free floor along both long edges is a workable minimum. Sliding shutters on a cupboard reduce the clearance needed in front of it.

Working Out Three Rooms

All three rooms below follow one rule. The cupboard takes 2 ft from one dimension, and the bed's head is against the other wall.

A 10 x 10 ft room

Subtract the cupboard's 2 ft from 10 ft and 8 ft is left. A queen bed is 5 ft wide, so 3 ft remains to share, which is 18 inches on either side. The bed itself runs 6.5 ft, so 3.5 ft of floor is free beyond its foot. The room serves a lone adult or a child well, and two adults on a queen bed will feel hemmed in.

A 10 x 12 ft room

The cupboard runs along the 10 ft wall, which leaves 10 ft in the other direction. A queen bed then has 2.5 ft free on each side, and a king bed cuts that to 2 ft. It is a sound choice for a children's room or a modest master, though a study table barely fits.

A 12 x 14 ft room

The cupboard runs along the 12 ft wall, leaving 12 ft in the other direction. A king bed leaves 3 ft on either side, and the room's other dimension leaves 5.5 ft past the bed's end. That is enough for a dresser, a desk or an armchair, so a master suite this big never feels crowded.

Reading the Numbers on a Plan

Most brochures print the distance between finished walls. Even so, it is wise to ask if that is the case, and whether niches or little corridors are counted in the total. A bedroom drawn as 11 x 13 ft could have the passage to its bathroom inside that figure.

Proportions matter as much as area, since a narrow rectangle holds less than a squarer room with the same floor area. Pillars that protrude into a room, and beams passing over where the bed will stand, are easier to spot on paper than after handover.

Where the Openings Fall

Doors and windows dictate the bed's position. Suppose the first wall has the door, the second a window, the third the bathroom door and the fourth a cupboard recess: then the headboard has nowhere to go. A plain wall at least 7 ft long is the one to look for.

Some further points mark the difference between a pleasant bedroom and an irritating one:

• The door swings back against a wall, so passers-by in the living area cannot see the bed
• The bathroom door is not close to the pillow end
• The window opens to the outside and does not face into the next flat
• The AC point, and the ledge outside for its outdoor unit, are in a sensible position
• The cupboard recess is 2 ft deep or more and broad enough to hold the household's clothes

A balcony linked to the bedroom adds daylight and fresh air, but its door eats into wall space. Rooms that back on to a lift shaft, a stairwell or the next flat's lounge pick up extra noise. The tower plan shows what is behind each wall.

Children's and Guest Rooms

Compact plans economise on the second and third rooms. For a child, room to play and a work table count for more than a large bed. Elderly parents are better served by a short walk to a bathroom, preferably attached, with a generously wide doorway.

The third room frequently turns into a study or guest room. With 10 ft of width, a single bed takes one long wall and a work table takes the other. A room only slightly wider than the legal minimum of 2.4 m makes a fair study but a cramped bedroom.

What to Do During a Visit

A tape measure and a single visit are enough for the following. They apply to a model flat as well as a finished home.

1. Measure length, width and height in each bedroom and match them to the plan
2. Scale the bed, cupboard and desk onto the plan, then measure the free walking strips
3. Pick out the plain wall that the headboard will use in each room
4. Spot the beams, pillars and the AC point
5. See what is visible through an open bedroom door from the entrance and the lounge
6. Read the tower plan to learn what adjoins each bedroom wall

Model flats usually carry undersized beds and slim cupboards, which flatter the rooms. Measure whatever furniture is on display before believing the impression. What binds the developer is the set of sizes in the sale agreement and in the plan attached to it.

Why Bedroom Size Matters

Calling a flat a two-bedroom or three-bedroom home only counts rooms. Two flats of equal carpet area can split it quite differently between the lounge, the sleeping rooms and the corridors, and a room one foot narrower may lose its bedside table or study desk.

Bedrooms are also the least adjustable part of a home. Since walls, windows and bathroom doors cannot be shifted later, furniture must adapt to them. Ten minutes with a tape and the plan prevents years of small daily frustrations.
